Converter/isolator of AC voltage to DC current/voltage, with AC input (0 ~ 500Vac) and current or voltage output (0-20mA and 4-20mA or 0-1 / 0-5 / 0-10 and 2 to 10Vdc). Galvanic insulation. DIN rail mounting. Power supply: 85~265 Vac/Vdc

Module with 3 channels of analog output (0 ~ 20mA, 4 ~ 20mA or -10 ~ 10 V, 0 ~ 10 V, 2 ~ 10 V) of 14 bits. RS-485 port. Modbus RTU communication (Requires Z-PC-DINAL2-17.5), Overload voltage protection, power supply 10 ~ 40 Vdc or 19 ~ 28 Vac

Module with 4 channels of analog inputs (± 2 Vcd / ± 10 Vcd / ± 20 mA) with 14-bit resolution. RS-485 port. Modbus RTU communication (Requires Z-PC-DINAL2-17.5), Overload voltage protection, power supply 10 ~ 40 Vdc or 19 ~ 28 Vac

Module with 4 independent and isolated input channels for platinum or nickel RTD (with 2,3 or 4 wires). RS-485 port. Modbus RTU communication (Requires Z-PC-DINAL2-17.5), MicroUSB on the front panel, power supply 10 ~ 40 Vdc or 19 ~ 28 Vac

Module with 8 channels of analog inputs (± 2Vcd / ± 10Vcd / ± 20mA) of 14-bit. RS-485 and RS-232 (DB9 Jack stereo 3.5 mm)port. Modbus RTU communication (Requires Z-PC-DINAL2-17.5), Overload voltage protection, power supply 10 ~ 40 Vdc or 19 ~ 28 Vac

External Relay interface for Z-PC modules

Mixed module with 16 CH digital inputs and 8 CH digital outputs, 32-bit counters in the inputs with a frequency of 10kHz, communication protocol: CANopen or ModBUS RTU (protocol selectable by dip-switch), power supply 10 to 40Vdc / 19 to 28Vac

24 CH DI module / CANOPEN-RS485 ModBUS RTU

24 CH DO module / CANopen-RS485 ModBUS RTU

8 CH Thermocouple (J,K,E,N,S,R,B,T) CANopen module

Module with a universal analog input (Voltage, Current, potentiometer, TC, RTD) and an active output 4 to 20mA or 0 to 20mA with PID regulation. Modbus RTU communication with RS-485 port (Requires Z-PC-DINAL2-17.5), power supply 10~40Vdc or 9~28Vac

Strain gauge module / CANOPEN

5 CH DI module / RS485 ModBUS RTU

5 CH DO Relay module / RS485 ModBUS RTU din rail mounting

1 slot 35mm DIN rail bus system for Z-PC Line I/O fast mounting and connection

DIN rail Plastic clip (spare part) for transducers T201 Series

Back rail mounting, expansion for digital Z-PC-DINAL2-17.5 (for 17.5 mm width devices), 2 slot block

Back rail mounting 17.5 mm (8 slots)

Head + 2 slots - 17/5 mm step (for Rs485 and power supply connections Z-line)

Strain gauge / load cell signal converter. Input for 4 or 6 wire. Input 1~64mV/V settable by DIP-switch or software, analog output configurable 0~20, 4~20 mA, 0~5 or 0~10 Vdc. Power supply 10~40Vdc or 19~28Vac, Modbus RTU.
